The value of K after the execution of this code shall be
(A) C (n + m – 1, m)
(B) C (n – m + 1, m)
(C) C (n + m – 1, n)
(D) C (n – m + 1, n)
Answer: (A)
2. In Delta Rule for error minimization
(A) Weights are adjusted w.r.to change in the output
(B) Weights are adjusted w.r.to difference between desired output and
actual output
(C) Weights are adjusted w.r.to difference between input and output
(D) None of the above
Answer: (B)
3. The concept of pipelining is most effective in improving performance
if the tasks being performed in different stages:
(A) require different amount of time
(B) require about the same amount of time
(C) require different amount of time with time difference between any two
tasks being same
(D) require different amount with time difference between any two tasks
being different
Answer: (B)
4. What is Granularity?
(A) The size of database
(B) The size of data item
(C) The size of record
(D) The size of file
Answer: (B)
5. Suppose that a given application is run on a 64-processor machine and
that 70 percent of the application can be parallelized. Then the expected
performance improvement using Amdahl’s law is
10. In an image compression system 16384 bits are used to represent 256 ×
256 image with 256 gray levels. What is the compression ratio for this
system?
(D) Neither Connection Oriented nor Connection Less
Answer: (A)
12. Which of the following can be used for clustering of data?
(A) Single layer perception
(B) Multilayer perception
(C) Self organizing map
(D) Radial basis function
Answer: (C)
13. Which of the following is scheme to deal with deadlock?
(A) Time out
(B) Time in
(C) Both (A) & (B)
(D) None of the above
Answer: (A)
14. If the pixels of an image are shuffled then the parameter that may change is
(A) Histogram
(B) Mean
(C) Entropy
(D) Covariance
Answer: (D)
15. The common property of functional language and logical programming
language:
(A) Both are declarative
(B) Both are based on l-calculus
(C) Both are procedural
(D) Both are functional
Answer: (A)
16. Given the following statements:
(i) The power of deterministic finite state machine and nondeterministic
finite state machine are same.
(ii) The power of deterministic pushdown automaton and nondeterministic
pushdown automaton are same.
Which of the above is the correct statement(s)?
(A) Both (i) and (ii)
(B) Only (i)
(C) Only (ii)
(D) Neither (i) nor (ii)
Answer: (B)
Answer: (B)
18. Consider a schema R (A, B, C, D) and functional dependencies A->B
and C -> D. Then the decomposition R1(A, B) and
R2(C, D) is
(A) Dependency preserving but not lossless join
(B) Dependency preserving and lossless join
(C) Lossless Join but not dependency preserving
(D) Lossless Join
Answer: (A)
19. The quantiser in an image-compression system is a
(A) lossy element which exploits the psychovisual redundancy
(B) lossless element which exploits the psychovisual redundancywww.netugc.com
(C) lossy element which exploits the statistical redundancy
(D) lossless element which exploits the statistical redundancy
Answer: (A)
20. Data Warehouse provides
(A) Transaction Responsiveness
(B) Storage, Functionality Responsiveness to queries
(C) Demand and Supply Responsiveness
(D) None of the above
Answer: (B)
21. A* algorithm uses f ' = g + h' to estimate the cost of getting from the
initial state to the goal state, where g is a measure of the cost of getting
from initial state to the current node and the function h' is an estimate of
the cost of getting from the current node to the goal state. To find a path
involving the fewest number of steps, we should set
(A) g = 1
(B) g = 0
(C) h' = 0
(D) h' = 1
Answer: (A)
22. The transform which possesses the highest ‘energy compaction’ property
is
(A) Slant transform
(B) Cosine transforms
(C) Fourier transforms
(D) Karhunen-Loeve transforms
Answer: (D)
Answer: (B)
24. The _______ memory allocation function modifies the previous allocated
space.
(A) calloc( )
(B) free( )
(C) malloc( )
(D) realloc( )
Answer: (D)
25. Which is not the correct statement(s)?
(i) Every context sensitive language is recursive.
(ii) There is a recursive language that is not context sensitive.
(A) (i) is true, (ii) is false.
(B) (i) is true and (ii) is true.
(C) (i) is false, (ii) is false.
(D) (i) is false and (ii) is true.
Answer: (B)
26. The mechanism that binds code and data together and keeps them secure
from outside world is known as
(A) Abstraction
(B) Inheritance
(C) Encapsulation
(D) Polymorphism
Answer: (C)
27. Identify the addressing modes of below instructions and match
them:
(a) ADI
(1) Immediate addressing
(b) STA
(2) Direct addressing
(c) CMA
(3)
Implied addressing
(d) SUB
(4) Register addressing
(A) a – 1, b – 2, c – 3, d – 4
(B) a – 2, b – 1, c – 4, d – 3
(C) a – 3, b – 2, c – 1, d – 4
(D) a – 4, b – 3, c – 2, d – 1
Answer: (A)
28. Which one of the following is not a Greibach Normal form grammar?
(i) S -> a | bA | aA | bB
A -> a
B -> b
(ii) S -> a | aA | AB
A -> a
B -> b
(iii) S -> a | A | aA
A -> a
(A) (i) and (ii)
(B) (i) and (iii)
(C) (ii) and (iii)
(D) (i), (ii) and (iii)
Answer: (C)
29. Which of the following IP address class is a multicast address?
(A) Class A
(B) Class B
(C) Class C
(D) Class D
Answer: (D)
30. While unit testing a module, it is found that for a set of test data,
maximum 90% of the code alone were tested with a probability of success 0.9.
The reliability of the module is
(A) atleast greater than 0.9
(B) equal to 0.9
(C) atmost 0.81
(D) atleast 1/0.81
Answer: (C)
31. The upper bound of computing time of m coloring decision problem
is
(A) O(nm)
(B) O(nm)
(C) O(nmn)
(D) O(nmmn)
Answer: (C)
Answer: (D)
33. Which one of the following statements is incorrect?
(A) The number of regions corresponds to the cyclomatic complexity.
(B) Cyclometric complexity for a flow graph G is V (G) = N – E + 2, where E
is the number of edges and N is the number of nodes in the flow graph.
(C) Cyclometric complexity for a flow graph G is V (G) = E – N + 2, where E
is the number of edges & N is the number of nodes in the flow
graph.
(D) Cyclometric complexity for a flow graph G is V (G) = P + 1, where P is
the number of predicate nodes contained in the flow graph G.
Answer: (C)
34. Consider a weighted undirected graph with positive edge weights and let
(u, v) be an edge in the graph. It is known that the shortest path from
source vertex s to u has weight 53 and shortest path from s to v has weight
65. Which statement is always true?
35. Consider the regular expression (a + b) (a + b) … (a + b) (n-times).
The minimum number of states in finite automaton that recognizes the
language represented by this regular expression contains
37. Are we building the right product? This statement refers to
(A) Verification
(B) Validation
(C) Testing
(D) Software quality assurance
Answer: (B)
38. The following postfix expression is evaluated using a stack 823^/23* +
51* –
The top two elements of the stack after first * is evaluated
(A) 6, 1
(B) 5, 7
(C) 3, 2
(D) 1, 5
Answer: (A)
39. The following CFG
S -> aB | bA, A -> a | as | bAA,
B -> b | bs | aBB
Generates strings of terminals that have
(A) Odd number of a’s and odd number of b’s
(B) Even number of a’s and even number of b’s
(C) Equal number of a’s and b’s
(D) Not equal number of a’s and b’s
Answer: (C)
40. Consider the following pseudo-code:
If (A > B) and (C > D) then
A = A + 1
B = B + 1
Endif the cyclomatic complexity of the pseudo-code is
(A) 2
(B) 3
(C) 4
(D) 5
Answer: (B)
41. Which layer of OSI reference model uses the ICMP (Internet Control
Message Protocol)?
(A) Transport layer
(B) Data link layer
(C) Network layer
(D) Application layer
Answer: (C)
Answer: (D)
Answer: (D)
44. Which diagram provides a formal graphic notation for modelling objects,
classes and their relationships to one another?
(A) Object diagram
(B) Class diagram
(C) Instance diagram
(D) Analysis diagram
Answer: (A)
45. A computer system supports 32 bit virtual address as well as 32 bit
physical addresses. Since the virtual address space is of same size as that
of physical address space, if we want to get rid of virtual memory, which
one of the following is true?
(A) Efficient implementation of multiuser support is no longer
possible.
(B) The processor cache can be made more efficient.
(C) Hardware support for memory management is not needed.
46. The feasible region represented by the constraints
x1 – x2< 1,
x1 + x2> 3,
x1> 0, x2> 0
of the objective function Max Z = 3x1 +
2x2 is
(A) A polygon
(B) Unbounded feasible region
(C) A point
(D) None of these
Answer: (B)
47. The colour of an object is largely determined by its diffuse reflection
coefficient. If Kd = (0.8, 0.4, 0), then what shall be the
colour of the object, if the light used is blue and magenta?
(A) White and Red
(B) Red and Blue
(C) Black and White
(D) Black and Red
Answer: (D)
48. If an instruction takes ‘i’ microseconds and a page fault takes an
additional ‘j’ microseconds. The effective instruction time, if on the
average a page fault occurs every k instructions, is
(A) i + j/k
(B) i + j * k
(C) (i + j)/k
(D) (i + j) * k
Answer: (A)
Answer: (B)
50. How many relations are there on a set with n elements that are
symmetric and a set with n elements that are reflexive and symmetric?
(A) 2n(n+1)/2 and 2n.3n(n–1)/2
(B) 3n(n–1)/2 and 2n(n–1)
(C) 2n(n+1)/2 and 3n(n–1)/2
(D) 2n(n+1)/2 and 2n(n–1)/2
Answer: (D)
51. The strategy used to reduce the number of tree branches and the number
of static evaluations applied in case of a game tree is
(A) Minmax strategy
(B) Alpha-beta pruning strategy
(C) Constraint satisfaction strategy
(D) Static max strategy
Answer: (B)
52. Match the following:
(i) Regular
Grammar
(a) Pushdown automaton
(ii) Context free Grammar
(b) Linear bounded automaton
56. ______ is sometimes said to be object oriented, because the only way to
manipulate kernel objects is by invoking methods on their handles.
(A) Windows NT
(B) Windows XP
(C) Windows VISTA
(D) Windows 95/98
Answer: (A)
57. A user level process in Unix traps the signal sent on a Ctrl + C input
and has a signal handling routine that saves appropriate files before
terminating the process. When a Ctrl + C input is given to this process,
what is the mode in which the signal handling routine executes?
(A) User mode
(B) Kernel mode
(C) Superuser mode
(D) Privileged mode
Answer: (B)
58. A CPU generally handles an interrupt by executing an interrupt service
routine
(A) As soon as an interrupt is raised
(B) By checking the interrupt register at the end of fetch cycle
(C) By checking the interrupt register after finishing the executing the
current instruction
(D) By checking the interrupt register at fixed time intervals
Answer: (C)
Answer: (B)
60. Radio signals generally propagate according to the following
mechanisms:
(A) Modulation, Amplification, Scattering
(B) Reflection, Diffraction, Scattering
(C) Amplification, Diffraction, Modulation
(D) Reflection, Amplification, Diffraction
Answer: (B)
61. Identify the devices given below with their IC numbers:
(i) USART
(a) 8251
(ii) Micro controller
(b) 8051
(iii) Interrupt controller
(c) 8259
(iv) DMA controller
(d) 8257
(i) (ii)
(iii)
(iv)
(A) (a)
(b)
(c)
(d)
(B) (b)
(a) (d)
(c)
(C) (c)
(d) (a)
(b)
(D) (d) (a)
(b)
(c)
Answer: (A)
62. The optimal solution of the following assignment problem using
Hungarian method is
I II
III
IV
A 8
26
17
11
B 13
28
4 26
C 38
19
18 15
D 19
26
24 10
(A) (B) (C) (D)
(A) (I) (II) (III) (IV)
(B) (I) (III) (II) (IV)
(C) (I) (III) (IV) (II)
(D) (I) (IV) (II) (III)
Answer: (B)
63. If a and b are the end points of a line, then which one of the
following is true?
(A) If both end points are left, right, above or below the window, the line
is invisible.
(B) If both end points are left, right, above or below the window, the line
is completely visible.
(C) If both end points are left, right, above or below the window, the line
is trivially visible.
(D) If both end points are left, right, above or below the window, the line
is trivially invisible.
Answer: (D)
64. Match the following with link quality measurement and handoff
initiation:
(a) Networked- Controlled Handoff (NCHO)
(i) MS connect to
BS
(b) Mobile- Assisted Handoff
(MAHO)
(ii) Process via channel the target BS
(c) Forward
Handoff
(iii)
First Generation Analog Cellular System
(d) Hard
Handoff
(iv)
Second Generation Digital Cellular System
(a) (b)
(c)
(d)
(A) (iii)
(iv) (ii)
(i)
(B) (ii)
(iii)
(i) (iv)
(C) (ii)
(i)
(iv)
(iii)
(D) (iv)
(iii) (i)
(ii)
Answer: (A)
65. Consider the methods used by processes P1 and
P2 for accessing their critical sections. The initial values
of shared Boolean variables S1 and S2 are
randomly assigned,
P1
P2
While (S1 = = S2);
while (S1 = =
S2);
Critical section
critical
section
S1 = S2;
S1 = S2;
Which one of the following statements describes the properties achieved?
(A) Mutual exclusion but not progress
(B) Progress but not mutual exclusion
(C) Neither mutual exclusion nor progress
(D) Both mutual exclusion and progress
Answer: (A)
66. If the period of a signal is 1000 ms, then what is its frequency in
kilohertz?
(A) 10–3 KHz
(B) 10–2 KHz
(C) 10–1 KHz
(D) 1 KHz
Answer: (A)
67. Let a * H and b * H be two cosets of H.
(i) Either a * H and b * H are disjoint
(ii) a * H and b * H are identical
Then,
(A) only (i) is true
(B) only (ii) is true
(C) (i) or (ii) is true
(D) (i) and (ii) is false
Answer: (C)
68. HTML is defined using SGML – an _______ standard, information
processing-text and office systems (SGML) for text information
processing.
(A) ISO – 8878
(B) ISO – 8879
(C) ISO – 8880
(D) ISO – 8881
Answer: (B)
69. What is the meaning of ‘Hibernate’ in Windows XP/Windows 7?
(A) Restart the computers in safe mode.
(B) Restart the computers in normal mode.
(C) Shutdown the computer terminating all the running applications.
(D) Shutdown the computer without closing the running applications.
Answer: (D)
70. Assume that we have constructor functions for both base class and derived class. Now consider the declaration in main ( ). Base * P = New
Derived; in what sequence will the constructor be called?
(A) Derived class constructor followed by Base class constructor.
(B) Base class constructor followed by derived class constructor.
(C) Base class constructor will not be called.
(D) Derived class constructor will not be called.
Answer: (B)
71. Which one of the following options is not a shell in UNIX system?
(A) Bourne Shell
(B) C Shell
(C) Net Shell
(D) Korn Shell
Answer: (C)
Answer: (D)
73. In which file the compiler manage the various objects, which are used
in windows programming?
(A) Control File
(B) Binary File
(C) Text File
(D) Obj File
Answer: (C)
74. On a disk with 1000 cylinders (0 to 999) find the number of tracks, the
disk arm must
move to satisfy all the requests in the disk queue. Assume the last request
service was at track 345 and the head is moving toward track 0. The queue in
FIFO order contains requests for the following tracks: 123, 874, 692, 475,
105, 376
(Assume SCAN algorithm)
(A) 2013
(B) 1219
(C) 1967
(D) 1507
Answer: (B)
75. Halftoning is defined as
(A) A technique to obtain increased visual resolution using multiple
intensity levels.
(B) A technique for using minimum number of intensity levels to obtain
increased visual resolution.
(C) A technique to obtain increased visual resolution using maximum number
of intensity levels.
(D) A technique for using appropriate number intensity levels to obtain
increased visual resolution.
0 Comments
